VISIBLE FAULT LOCATOR – SUIT 2.5MM
Visible Fault Locator Suit 2.5mm
The MSS Pocket Fault Locator is designed for either singlemode or multimode use. The pocket-sized unit allows you to visually locate micro-bends, fibre breaks, and other sources of optical attenuation in fibre Patch Leads, Patch panels, and Enclosures.
The class 2 visible laser operates at 650nm in both continuous and pulse modes. The unit has a 30 hour battery life in continuous mode and 40 hours in modulated mode.
This unit includes batteries and protection holster.
Visible Fault Locator Features
- All Aluminium construction
- 650nm laser
- 2.5mm or 1.25mm universal adapter
- Finds sharp bends and breaks
- Test for continuity
- 6-7km Singlemode
- 4-5km Multimode
- Nylon belt holster
- Extra-long battery life with 2x AA batteries
- Continuous and modulated modes
Technical Data
| Wavelengths | 650nm+/- 5nm |
| Fibre-coupled output | 0dBm typical, -3.5dBm minimum (singlemode fibre) |
| Laser Class | III (< 5mW) |
| Approx Range | 6-7km (singlemode), 4-5 (multimode) |
| Battery | (2) AA |
| Battery Life | 30hrs continuous, 40hrs modulated |
| Adapter | Universal 2.5mm or 1.25mm |
| Dimensions | 7.1″ long x 0.860″ diameter |
| Weight (with batteries) | 127gms |
| Operating Temp | -10 to 50 |
Ordering Information
| Part No. | Description |
| VFL-HD | Visible Fault Locator (Pocket) Suit 2.5mm |
| VFL-LC | Visible Fault Locator (Pocket) Suit 1.25mm |
