RUBBER GROMMET 25MM
Flexible Rubber Grommet 25MM Black
Flexible rubber grommets protectwires from sharp corners in a panel and chassis hole.
Flexible Rubber Grommet 25MM Black:
- Protect wires from sharp corners in panels and chassis holesÂ
- Available in a range of sizesÂ
- Range of pack sizes from 25, 50 and 100
Technical Data:
- Material:Â Rubber
Ordering Information:
Line drawings for dimensions (A, B,C and E) are available. See Brochures and Images under Product Resources and select the latest Brochure or Catalogue.
Part No. |
Hole Size A |
Chassis Thickness |
Dimensions (mm) | |||
Inner Dia. B |
Outer Dia. C |
Height E |
Pack Size |
|||
RGM6Â Â | 6.0 | 1.7 | 3.0 | 8.5 | 4.7 | 100 |
RGM7Â Â | 7.2 | 1.7 | 5.0 | 10.2 | 4.4 | 100 |
RGM10 | 10.0 | 1.7 | 6.4 | 13.3 | 6.3 | 100 |
RGM20 | 20.0 | 1.5 | 15.5 | 23.0 | 6.5 | 50 |
RGM25 | 25.0 | 1.5 | 18.9 | 31.0 | 8.0 | 25 |
RGM32 | 32.0 | 1.5 | 25.0 | 38.1 | 7.8 | 25 |
RGM50 | Solid | 1.5 | – | 58.0 | 8.0 | 25 |
