Nylon Cable Tie Heavy Duty 370 *7.6Mm Re

NYLON CABLE TIE HEAVY DUTY 370 *7.6MM RE

Nylon Releasable Cable Tie UV Black 370 x 7.6MM 100 PK

Halogen free nylon releasable cable ties meet the most basic of cable tie needs, with choices suitable for a wide range of size and strength requirements.

The one piece, injection moulded construction provides maximum strength and adjustability for securing all sizes of bundles. Extra features such as rounded edges and bent tip design make installation fast, easy, accurate and secure. Installation tools are not required but are suggested where controlled, uniform tension and cut-off applications are desired.

Note: Exterior applications should use black (UV stabilised) ties.

Nylon Releasable Cable Tie UV Black 370 x 7.6MM 100 PK Features:

• Heavy-duty releasable head/pawl integrally moulded for added strength and durability. Tip designed for easier pick up, insertion and pull through
• Smooth round edges do not cut insulation
• Self-locking low profile head conserves space

Technical Data:

Conformant Standards
UL; Mil Spec; IEC; VDE; DIN

Refer
MS 3367 MS 3368 physical dimensions
Mil-S-23190E testing
Mil-Std-105D sampling
Mil-C-45662 test equipment calibration
Mil-1-45208A QC manual and systems

Smoke Emission
Low smoke / Halogen free

Material
NATURAL – Nylon 66 with additives
BLACK – Nylon 66 with UV stabilisers Material Tensile Strength
80 N/mm² or 11200 psi

Operating Temperature
-40°C to 85°C

Flammability
Passed – U.L. 94V-2

UV Stability
Exceeds ASTM-D-4066 with
2.5% carbon black giving nominal 15 years normal exposure to UV with less than 10% yield in tensile strength

Electrical Data
Breakdown voltage 20 kV/mm
Volume resistivity 2 x 1010 ohm
Moisture content 2.5% w.v. @ 23%/50%RH
