HDMI 4K Splitter UHD 10.2Gbps
These 4K UHD HDMI Splitters are advanced solutions for splitting and distributing a single HDMI input across multiple HDMI outputs. They deliver high performance video output up to 4K@60Hz (YUV 4:2:0) resolution Support pass-through of HD digital audio formats such as LPCM 7.1, Dolby Digital Plus, Dolby TrueHD, Dolby Atmos and DTS-HD Master Audio, with audio sampling rates up to 192kHz. The included System Reset function allows the unit to reset the TV to its default HDMI input automatically via CEC commands.
HDMI 1.4 with 4K UHD, HDCP 1.4 and DVI 1.0 compliant
1 HDMI input and 2 HDMI outputs
System Reset function support (CEC active source command)
Simultaneous display of a single 4K UHD source across up to 8 displays
3D pass-through with compatible 3D source and 3D TV
Supports 4K UHD resolutions up to and including: 3840×2160 & 4096×2160
Supports pass-through of HD audio: LPCM 2.0/5.1/7.1, Dolby Digital, DTS, Dolby TrueHD, Dolby Atmos and DTS-HD Master Audio
Supports “Standard” mode and “TV” mode for EDID settings management
Inputs 1x HDMI [1x Uncompressed AV and Data]
1x USB Mini-B [1x SERVICE Propriety Data]
Outputs 4x HDMI [4x Uncompressed AV and Data]
PSU: 5V/1.2A
Dimensions 161mm [W] x 26mm [D] x 76mm [H]
Net Weight 311g
