Gigabit WDM Media Converter 20km

Gigabit WDM Media Converter 20km

SKU: TL-FC311B-20

$71.00 Incl. GST
You save (%)

Let me know if the price goes down
Send
Add to Wishlist

Gigabit Wavelength Division Multiplexing Media Converter 20km

SKU: TL-FC311B-20 Categories: , Brand: Shipping, Availability & Return Information

Sometimes exact stock levels are not reflected on the website and for this reason, deliveries could be delayed. If a product is in stock, we aim to dispatch and deliver between 1-4 working days, subject to customer location. In the unlikely event of product being out of stock, customer is contacted via mail/phone at the earliest. On a few occasions, distributors also run out of stock causing further delays. If this be the case, we try our best to keep customer informed of order progress.

1300 178 620

Gigabit WDM Media Converter 20km

TL-FC311A-20 and TL-FC311B-20 adopt WDM (wavelength division multiplexing) technology, helping send and receive data at a distance of up to 20 km with only a single-mode fibre, which saves half of the cable deployment cost for customers. TL-FC311A-20 transmits data at 1550 nm wavelength and receives data at 1310 nm wavelength on optical fibre. Therefore, the terminal device used in conjunction with the TL-FC311A-20 should send data at a wavelength of 1310 nm and receive data at a wavelength of 1550 nm. TP-Link another media converter TL-FC311B-20 is one of the products that can cooperate with TL-FC311A-20.

  • 1× 10/100/1000Mbps Auto-Negotiation RJ45 port supports Auto-MDI/MDIX
  • Auto-negotiation of Half-Duplex/Full-Duplex transfer mode
  • Adopts WDM technology, transmitting and receiving data on one single fibre
  • Extends fibre distance up to 20 km
Manufacturer

TP-Link
Rx.

1550nm
Tx.

1310nm

Reviews

There are no reviews yet.

Be the first to review “Gigabit WDM Media Converter 20km”
Gigabit WDM Media Converter 20km_Brochure
