DVI TO 3G-SDI Video Converter With Audio 480i-1080p

Name: DVI TO 3G-SDI Video Converter With Audio 480i-1080p
Brand: Cypress
SKU: CLUX-DVI2SDIA
Price: 606 AUD
Availability: InStock
Rating: 5 (1 reviews)

SKU: CLUX-DVI2SDIA

$606.00 Incl. GST

Let me know if the price goes down

Your name

Your email

Send

QUICK OVERVIEW

DVI TO 3G-SDI Video Converter With Audio 480i-1080p

SKU: CLUX-DVI2SDIA Categories: Media Converter, Network Hardware Shipping & Returns Information

Sometimes exact stock levels are not reflected on the website and for this reason, deliveries could be delayed. If a product is in stock, we aim to dispatch and deliver between 1-4 working days, subject to customer location. In the unlikely event of product being out of stock, customer is contacted via mail/phone at the earliest. On a few occasions, distributors also run out of stock causing further delays. If this be the case, we try our best to keep customer informed of order progress.

Seen it cheaper? Ask our team for a CABLESONLINE Deal.

1300 178 620

DVI TO 3G-SDI Video Converter With Audio 480i-1080p

DVI to SDI converter with Audio

TRANSMIT ANALOGUE AUDIO & DVI VIDEO ON 3G-SDI

The DVI to SDI Converter allows DVI-D signals to be shown on an SDI display while ensuring high bit rates of 2.970 Gbit/s to give you high resolution signals without any loss. For professionals this means that it is now easier to convert your high definition DVI signals (with audio) to SDI for long distance transmission to display your media on an SDI display. In addition, the external audio input allows the user to insert the sound from a different audio source instead of the DVI embedded audio, and send to the SDI output. Supports DVI input up to 1080p.

DVI signal conversion to SDI signal
Supports DVI input resolutions of:
– [email protected] and 576i
– 720p@50/59.94/60Hz and 1080i@50/59.94/60Hz
– [email protected]/24/25/29.97/30/50/59.94/60Hz
Operation at bitrates of 270Mbps, 1.485Gbps, 1.485/1.001Gbps, 2.970Gbps and 2.970/1.001Gbps
Supports SDI standards of:
– SMPTE 259M-C@270Mbps
– SMPTE [email protected] and 1.485/1.001Gbps
– SMPTE 424M and SMPTE 425M (Level A and Level B)@of 2.970Gbps and 2.970/1.001Gbps
Converts DVI signals to SDI signals:
– 480i and 576i to SD-SDI/SMPTE 259M-C
– 720p and 1080i to HD-SDI/SMPTE 292M
– 1080p to 3G-SDI/SMPTE 424M and SMPTE 425M (Level A and Level B)
Supports SDI output distance up to 300m (SD-SDI), 200m (HD-SDI) or 100m (3G-SDI)

Brand	Cypress
Input	1x DVI
Output	1x SDI
Input Video Formats	Digital RGB
Output Video Formats	SD/HD/3G-SDI
Supported TV Resolutions	480i-1080p
Supported PC Resolutions	VGA-WUXGA (RB)
