Cabflx CNM32OR-30 Liquid Tight Non Metal Orange 32Mm X 30M

Flexible spiral wound PVC conduit made from a Very Hard PVC Spiral encased in a PVC
extrusion giving us a High Strength Smooth Bore Conduit
UV stabilized orange PVC jacket Operating Temp of -20 to +80 deg Superior Chemical
Resistance
Suitable for Food Prep environments, Minning Applications, Water Treatment
Machine Wiring and other Industrial Areas PVC fittings available but can
Also, be used with CABFLX Steel Brass and Stainless Steel Fittings
Liquid Tight Non-Metallic Type CNM Conduit Orange
CABFLX non-metallic liquid tight conduit is comprised of a very hard PVC spiral encased in a
PVC outer jacket, producing high strength, smooth bore conduit suitable for a diverse range of
applications.
Our type CNM non-metallic conduit features a variety of performance characteristics that make
it an excellent choice for use in food preparation environments, mining applications, machine wiring, air conditioning hook-ups, and many other outdoor applications. These characteristics
include flexibility, durability, chemical resistance, and UV protection. In addition to providing
excellent abrasion protection, our liquid-tight PVC conduit is resistant to sunlight, mild acids,
alkalis, and oils.
While we stock PVC terminator fittings specifically designed for the CNM range, this conduit can
also be used with CABFLX steel, brass or stainless-steel liquid tight fittings.
Technical Data
Material: PVC
Colour: Orange
Working Temperature: -20 to +80 degrees Celsius
Nominal Size: 32mm
ID: 26.7mm
OD: 33.1mm
Min Inside Bend: 165mm
Carton Reel Length: 30m
