APC UPS 1600VA/230V AVR Australian Sockets Battery Backup & Surge Protector

APC UPS 1600VA/230V AVR Australian Sockets Battery Backup & Surge Protector-11143
APC UPS 1600VA/230V AVR Australian Sockets Battery Backup & Surge Protector-11144

APC UPS 1600VA/230V AVR Australian Sockets Battery Backup & Surge Protector

SKU: UPAPCBX1600MI-AZ

$331.00 Incl. GST

In stock

Send
Add to Wishlist

APC UPS 1600VA/230V AVR Australian Sockets Battery Backup & Surge Protector

SKU: UPAPCBX1600MI-AZ Categories: , Shipping & Returns Information

Sometimes exact stock levels are not reflected on the website and for this reason, deliveries could be delayed. If a product is in stock, we aim to dispatch and deliver between 1-4 working days, subject to customer location. In the unlikely event of product being out of stock, customer is contacted via mail/phone at the earliest. On a few occasions, distributors also run out of stock causing further delays. If this be the case, we try our best to keep customer informed of order progress.

APC UPS 1600VA/230V AVR Australian Sockets Battery Backup & Surge Protector

Back-UPS Features & Benefits

Availability

Automatic self-test

Periodic battery self-test ensures early detection of a battery that needs to be replaced.
Intelligent battery management

Maximizes battery performance, life, and reliability through intelligent, precision charging.
Battery failure notification

Provides early-warning fault analysis on batteries enabling timely preventive maintenance

Safety

Safety-agency approved

Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.

Protection

Surge only outlets

Protect secondary electronics from surges and spikes without reducing battery power used to run primary electronics during an outage.
Battery and surge protected outlets

Back up and protect your hardware and data during power outages, surges and spikes .

Marketing features

Battery-protected and surge-only outlets

Reserves power capacity and run time for connected equipment that require UPS battery back-up while providing surge only protection for less critical equipment

Manageability

Audible alarms

Provides notification of changing utility power and UPS power conditions
LED status display

Quickly understand unit and power status with visual indicators.

Product Distribution

Australia

Technical Specifications

Output

Max Configurable Power (Watts)

900 Watts / 1.6kVA
Output Frequency (sync to mains)

50/60 Hz +/- 1 Hz Sync to mains
Topology

Line interactive
Waveform type

Stepped approximation to a sinewave
Transfer Time

6 ms typical : 10 ms maximum

Input

Input frequency

50/60 Hz +/- 5 Hz Auto-sensing
Input voltage range for main operations

140 – 300V
Number of Power Cords

1
Input Power Factor at Full Load

0.56

Batteries & Runtime

Battery type

Lead-acid battery
Typical recharge time

8hour(s)
Nominal Battery Voltage

24 V
Expected Battery Life (years)

3 – 5
Battery Volt-Amp-Hour Capacity

168

Communications & Management

Control panel

LED Status display with on line : on battery
Audible Alarm

Alarm when on battery : distinctive low battery alarm

Surge Protection and Filtering

Surge energy rating

273Joules
Data Line Protection

RJ45 10/100/1000 Base-T Ethernet protection

Physical

Maximum Height

190MM, 19.0CM
Maximum Width

140MM, 14.0CM
Maximum Depth

390MM, 39.0CM
Net Weight

10.3KG
Shipping weight

11.3KG
Shipping Height

297MM, 29.7CM
Shipping Width

235MM, 23.5CM
Shipping Depth

495MM, 49.5CM
Color

Black
SCC Codes

10731304410772

Environmental

Operating Temperature

0 – 40 °C
Operating Relative Humidity

0 – 95 (Non-condensing) %
Operating Elevation

0 – 3000meters
Storage Temperature

-15 – 40 °C
Storage Relative Humidity

0 – 95 (Non-condensing) %
Storage Elevation

0 – 3000meters
Audible noise at 1 meter from surface of unit

40.0dBA
Protection Class

IP20

Conformance

Approvals

CB , CE, EN/IEC 62040-1, EN/IEC 62040-2, RCM
Equipment protection policy

Lifetime : 50000 euros
Standard warranty

2 years repair or replace

Sustainable Offer Status

RoHS

Compliant
